Features of compression gas spring

Production Range

General Information about our gas spring

Safety：
Gas springs are for lifting and supporting objects and may not be used as a safety device.
It is recommended that gas compression springs and gas traction springs be stored piston rod downwards.

Nitrogen is an inert gas environmentally friendly does not burn and is not a danger to public health.

as springs should always be installed with the piston rod downwards.
Drying out of the piston rod seal will result in a decreased number of cycles and lifetime of the gas spring.

Standard gas springs work at temperatures of -30ºC up to +80ºC.
For special request of low temperature area, we can make the gas spring with working temperatures of -40 ºC

Gas springs are under high pressure up to 300 BAR/4351.14 Psi and may under no circumstances be opened exposed to heat or fire, be drilled or subject to any other improper use or modification.
Each gas spring is labelled with the year of production, description and the text “Danger do not open and damage High pressure / Danger!

RoHS COMPLIANCE：
Shuangyuan Gas Springs have been identified as RoHS compliant

Delivery：
Sample, about 7 days
Mass Production, 15-30 days depending the order quantity

Certificate:
We are ISO9001:2015 certificated
Scope: Manufacturing and Design of high quality gas spring

Warranty：
Our gas spring have a warranty of 12 months after delivery date against defects in material or workmanship in normal use. Any product that is found to be defective under normal use, will be repaired or replaced under warranty time

Application:
Treadmill,Automotive,Tool Box etc

Working Temperature:

Low temperature test :conduct(-40C,24h)

High temperature test : conduct(85C,48h)
